Circulation Pump Wilo Star-RS 15/5 - 130 mm

Application:

Glandless circulation pump with threaded connection designed for use in hot water heating systems, air conditioning, and industrial circulation systems. The device ensures efficient circulation of the heating medium, while the manual three-stage speed control allows precise adjustment of the pump operating parameters to the demands of the installation.

Main Features:

- 3-Stage Power Control: The speed selector switch allows adjustment of performance and power consumption to the current system requirements.
- Optimal Flow and Delivery Head: Delivery head of up to 5 m ensures effective pumping of the medium in the system.
- Compact Overall Length: Standard overall length of 130 mm facilitates installation in tight spaces.
- High Pressure Resistance: Designed for safe operation at a working pressure of up to 10 bar (PN 10).
- Universal Threaded Connection: Connection diameter G 1 enables easy and quick installation into the system.

Technical Data:

- Manufacturer / Product Name: Wilo Star-RS
- Delivery Head: 5 m
- Three-Stage Power Consumption: 46 W / 67 W / 93 W
- Mains Voltage: 1~220V 50 Hz
- Maximum Operating Pressure: 10 bar (PN 10)
- Overall Length: 130 mm
- Inlet / Outlet Connection: G 1
- Protection Class: IP 42
